Fire-resistant cylinder storage cabinets are cabinets made of durable materials, especially designed to safely store hazardous or flammable gases. These cabinets minimize the risk of gas cylinders exploding or leaking in the event of a fire. Their general features are as follows:

1. Fire-resistant materials: Cabinets are generally made of durable and high-temperature-resistant materials such as steel.

2. Fire-retardant coating: There are special coatings on the inner and outer surfaces of the cabinets that control the internal temperature of the cabinet in the event of a fire.

3. Ventilation system: They can be equipped with ventilation systems against possible leaks from gas cylinders.Optional

4. Safety locks: There are special lock systems to prevent access by unauthorized persons and to ensure security.

5. Warning signs: Warning signs indicating that hazardous materials are stored and precautions to be taken against fire hazards are indicated on the cabinet.

Type G90 Gas cylinder cabinet

Free-standing unit with wing door (hinged on the left)

With cylinder locking (integrated in the turning handle)

Version for 2x 50-litre cylinders

Integrated adjustment aids to compensate for uneven ground

G-LINE model range

model class G-ULTIMATE-90

Model G90.205.060.2F

Type tested in accordance with EN 14470-2

DIN EN 16121/16122

GS certified

CE compliant

External dimensions: W x D x H (mm) 598 x 615 x 2050

Internal dimensions: W x D x H (mm) 477 x 425 x 1858

Colour

Body colour light grey (RAL 7035)

Light grey wing door (RAL 7035)

Interior equipment

1 x standard interior equipment gas cylinders, mounting rails, rolling ramp and roller holder, galvanized and powder coated sheet steel
